LiteScope Package

The LiteScope pack consists of:

LiteScope : scanning head
NenoBox – control unit
NenoView – software control
SEM adapter
Vacuum passage
Wiring

LiteScope - scan head

LiteScope is an AFM microscope designed for quick and easy integration within SEM instruments (operational as a stand-alone AFM as well).

Supports correlative probe and electron microscopy ( CPEM ) technology Comprehensive surface characterization: topography, roughness, electrical and mechanical properties of the material Compact design compatible with most SEM systems Easy SEM assembly/disassembly in less than five minutes Compatible with FIB, GIS, EDX and other accessoriesAutosensing probes without optical detection or laser adjustmentHighly customizableOptional scanner configurationsOptional macro focus configurationMagnetic immersion or fieldless SEM versions availableSpecial modules and accessories

Nenobox - control unit

All of the electronics that run LiteScope are integrated into one control unit, replacing the need for an additional dedicated computer. This unit is a standard 19” rack and can be easily mounted in the free slot of the SEM electronics or simply placed free to suit the needs of the task at hand.

Maximum PLL (Phase Locked Loop) frequency for dynamic measurements 75 kHz suitable for tuning fork based probes (or higher using external PLL or as per customer requirements) 2 × 16 bit per scan axis DAC to achieve maximum resolution anywhere within the field of view 5x16-bit auxiliary inputs for simultaneous measurements of user signals (±10 V) Input signals can be used in a four-channel feedback loop mixer External probe drive ethernet connection Preamplifier is located inside the body of the LiteScope™, ensuring a significant reduction in electrical interference.

NenoView - control software

NenoView is a user-friendly web-based software that allows us to fully control setup measurements, data acquisition and data processing. NenoView supports CPEM technology and allows you to use correlative images directly and internally.

Web-based user interface Remote access to user data Remote control of experiments via tablet, smartphone, etc. Easy for new users, flexible for expertsSaves data with all information, including measurement settingsIndividually configurable user accountsOne data download from control PC to local computerIntegrated data post-processing, analysis, export, etc.
